Airtac B52-GZ Non-Copper Shut-Off Valve B52-GZ20006
AirTAC B52-GZ Copper-Free Shut-off Valve B52-GZ20006 Specifications
- Model: B52-GZ20006
- Type: 2-port normally open manual shut-off valve
- Port size: PT1/4 (G1/4 equivalent)
- Body material: Aluminum alloy with copper-free treatment
- Seal material: Fluororubber (FKM)
- Operating pressure: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -10℃ to 150℃
- Flow coefficient (Cv): 4.2
- Weight: 320g ±5g
- Dimensions: 76mm(L) × 34mm(W) × 34mm(H)
- Thread standard: ISO 228/1 (BSPP)
- Leakage rate: ≤3 bubbles/min (JIS B8376 test)
- Surface treatment: Black anodized
Heavy-duty manual shut-off valve featuring copper-free construction for chemical compatibility, designed to prevent copper particle contamination in sensitive systems. The dual-seal structure with fluorocarbon elastomer ensures reliable sealing in high-vibration environments. Includes ergonomic lever with positive ON/OFF tactile feedback.
- Semiconductor manufacturing gas lines
- Oxygen supply systems (medical/industrial)
- Chemical dosing systems with corrosive media
- High-purity pneumatic circuits in food processing
- Vacuum system isolation points
Installation note:
Apply 24-hour pressure test after installation. Lubricate threads with fluorocarbon-compatible grease.
Arrow markings indicate flow direction - reverse installation may compromise sealing.
