Airtac CPV10S Integrated Manifold Valve CPV10SJ04B18F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B18F Technical Details
- Model: CPV10SJ04B18F (CPV10S series)
- Valve type: 4-port, 5-position integrated manifold
- Port configuration: 1/4" NPT (G1/8 optional)
- Operating pressure range: 0.2–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil insulation class: Class F (155℃)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 450g ±5% (with manifold base)
- Dimensions: 72mm(L) × 40mm(W) × 85mm(H)
- Port spacing: 18mm center-to-center
- Protection rating: IP67 (dust/water resistant)
- Compliance: RoHS2.0, REACH
Modular pneumatic control solution combining 4 independent 3/2-way valves in a space-saving aluminum alloy body. Features zero-pressure differential operation capability and optimized flow paths for reduced air turbulence. Includes built-in surge suppression and LED operation indicators. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particles).
- Multi-axis pneumatic actuator synchronization
- Bottle capping machine sequencing systems
- Automated textile machinery tension control
- Lithium battery production line tooling
- Plastic injection molding ejector control
Installation guidelines:
Mount on flat surface using M4 screws (max torque 1.2N·m).
Maintain 20mm clearance below manifold for tubing access.
Use copper-free lubricants if required. Perform 5-minute
dry cycling before initial operation.
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B18F |
