Airtac ESV Solenoid Valve ESV210AI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210AI Solenoid Valve Technical Details
- Model: ESV210AI (ISO 15407-1 compliant)
- Valve type: 5/2-way single solenoid with spring return
- Port configuration: G1/4 (BSPP thread standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Ambient temperature: -10℃ to 80℃ (14°F to 176°F)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (dust tight & protected against temporary immersion)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 220g ±5% (excluding connector)
- Dimensions: 55mm(L) × 35mm(W) × 70mm(H) (manual override button adds 8mm)
The ESV210AI features a rugged aluminum alloy body with anodized surface treatment, designed for high-cycle industrial applications. Its zero-pressure differential start capability and low power consumption (≤2.5W) make it suitable for energy-sensitive systems. The valve incorporates a magnetic latching mechanism for failsafe operation and includes a manual override for system debugging.
- High-speed packaging machinery cylinder control
- Plastic injection molding machine ejector systems
- Semiconductor wafer handling robots
- Food processing equipment (compatible with NSF-H1 grease)
- Automated assembly line clamping mechanisms
Installation requirements:
Maintain 0.5-1.0mm alignment tolerance during manifold mounting.
For horizontal installation, ensure exhaust ports face downward to prevent
debris accumulation. Use Loctite 545 thread sealant for leak-free piping connections.
| Property | Property Value |
|---|---|
| sku | ESV210AI |
| Standard Voltage | AC220V |
