Airtac ESV Solenoid Valve ESV210C
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210C Solenoid Valve Technical Specifications
- Model: ESV210C (Enhanced Stability Version)
- Type: 5/2-way monostable (pilot-operated)
- Port size: G1/4" (ISO standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤20ms (at 0.5MPa)
- Flow rate: 750 Nl/min (Cv=1.2)
- Weight: 200g ±5% (without connector)
- Dimensions: 50mm(L) × 35mm(W) × 65mm(H)
- Seal material: FKM fluorocarbon (standard), optional EPDM
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-flow solenoid valve with optimized spool structure for reduced pressure loss. Features dual-chamber sealing technology and gold-plated terminals for reliable performance in humid environments. Requires 5μm filtered air with oil mist lubrication (ISO 8573-1 class 4). Compatible with vacuum applications when paired with vacuum-rated seals.
- Automated assembly line actuators
- Plastic injection molding machines
- Semiconductor wafer handling systems
- Food packaging equipment (food-grade versions available)
- Electric vehicle battery cooling systems
- Robotic gripper control systems
Installation guidelines:
Use vibration-resistant mounting brackets in mobile applications.
For horizontal installation, ensure exhaust ports face downward.
Maintain 0.5m minimum distance from high-frequency inverters.
Critical note:
Always install downstream pressure regulators.
Do NOT use silicone-based lubricants - compatible only with
petroleum-based pneumatic oils (ISO VG32 or equivalent).
| Property | Property Value |
|---|---|
| sku | ESV210C |
| Standard Voltage | AC 110V |
