Airtac ESV Solenoid Valve ESV210FI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV210FI Solenoid Valve Technical Specifications
- Model: ESV210FI (ISO 15407-1 compliant)
- Type: 5/2-way monostable (single solenoid) with manual override
- Port size: G1/4" (BSPP thread standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V/24V ±10%, AC110V/220V ±10% (50/60Hz)
- Weight: 480g ±2% (including coil and connector)
- Dimensions: 56mm(W) × 37mm(H) × 98mm(L)
- Seal materials: HNBR (Hydrogenated Nitrile) standard, optional FKM/Viton®
- Temperature tolerance: -10℃ to 80℃ (with NBR seals), -20℃ to 150℃ (FKM option)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Valve body material: Anodized aluminum alloy (ADC12)
- Installation orientation: Any (360° mountable)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Protection class: IP67 (coil), IP40 (valve body)
High-flow proportional solenoid valve with position feedback signal (optional Hall sensor). Features zero-pressure differential start capability and optimized spool geometry for reduced stick-slip effect. Compatible with ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content). Includes LED status indicator and surge protection circuit.
- Automated assembly line cylinder sequencing
- Plastic injection molding machine clamp control
- CNC tool changer positioning systems
- Food processing pneumatic actuators (NSF-certified version available)
- Lithium battery production dry room environments
Installation requirements:1. Use 5μm filtration with automatic drain
2. Maintain 80% maximum duty cycle for AC coils
3. Allow 20mm lateral clearance for heat dissipation
4. Torque limit: 12-15N·m for port connections
5. Compatible with ISO 1179-2 pneumatic fittings
| Property | Property Value |
|---|---|
| sku | ESV210FI |
| Standard Voltage | DC12V |
