Airtac ESV Solenoid Valve ESV220A
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220A Solenoid Valve Specifications
- Model: ESV220A
- Type: 5/3-way double solenoid operated (closed center)
- Port size: G1/4 (NPT1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Weight: 450g ±5%
- Dimensions: 80mm(L) × 40mm(W) × 100mm(H)
- Seal material: Heat-resistant FKM (Viton®)
- Temperature range: -10℃ to 90℃ (with FKM seals)
- Power consumption: 2.2W (DC24V), 3.5VA (AC220V)
- Flow capacity: CV 1.8 (Kv 1.55)
- Response time: ≤25ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤10% of rated voltage
High-flow directional control valve with manual override, designed for industrial automation systems requiring precise mid-position control. Features brass body with electroless nickel plating for chemical resistance, and dual-coil design with surge protection diodes. Compatible with ISO 15407-1 standards. Requires 5μm filtered dry air with max 10,000ppm oil content.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Pneumatic cylinder sequencing in packaging equipment
- Test bench pressure regulation systems
- Food processing machinery (with optional NSF-certified seals)
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm minimum clearance around exhaust ports for proper venting.
Use copper-free grease on threads for leak-proof sealing.
| Property | Property Value |
|---|---|
| sku | ESV220A |
| Standard Voltage | AC220V |
