Airtac ESV Solenoid Valve ESV220AI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220AI Solenoid Valve Technical Specifications
- Model: ESV220AI
- Type: 5/2-way double solenoid (dual coil) with manual override
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure range: 0.15–1.0 MPa
- Max flow rate: 1200 NL/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Weight: 350g ±5% (excluding accessories)
- Dimensions: 78mm(L) × 48mm(W) × 62mm(H)
- Body material: Reinforced PBT with UL94 V-0 rating
- Seal material: FKM/Viton (-10℃ to 150℃)
- Response time: ≤15ms (exhaust to atmosphere)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 10mm (minimum engagement)
- Max allowable backpressure: 80kPa
High-flow proportional control valve featuring dual-coil latching design for energy efficiency. Equipped with LED status indicators and surge protection circuitry. The ESV220AI's optimized flow path reduces pressure drop by 25% compared to previous generation models. Requires 5μm filtered lubricated air (ISO 8573-1 class 3). Compatible with ISO 15407-1 mounting interfaces.
- Multi-station pneumatic indexing systems
- Automated assembly line clamping mechanisms
- Plastic injection molding machine controls
- Semiconductor wafer handling robotics
- High-cycle packaging equipment (500+ operations/minute)
Installation requirements:
Maintain vertical mounting position (±5° tolerance). For horizontal piping runs,
install downstream moisture separator. Allow 15mm clearance around coils
for heat dissipation. Use M3.5 mounting screws with 0.4-0.6Nm torque.
- Connector type: DIN43650 Form C (optional flying lead)
- Wire gauge: 18-22 AWG
- Insulation resistance: ≥100MΩ (500VDC megger test)
- Dielectric strength: 1500VAC/1min (coil to frame)
| Property | Property Value |
|---|---|
| sku | ESV220AI |
| Standard Voltage | AC220V |
