Airtac ESV Solenoid Valve ESV220B
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220B 5/2-Way Solenoid Valve Technical Details
- Model: ESV220B
- Valve type: 5/2-way single/double solenoid (pilot-operated)
- Port configuration: G1/8 (NPT1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V/24V, AC110V/220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Flow capacity (Cv value): 1.6
- Response time: ≤20ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Port thread depth: 12mm (full engagement)
- Weight: 0.52kg ±2% (with coil)
- Dimensions: 55mm(W) × 40mm(H) × 105mm(L)
- Protection class: IP65 (dust/water jet resistant)
- Electrical connection: DIN43650 Form A connector
- Manual override: Optional side-mounted paddle
The ESV220B features zero-pressure differential start capability and anti-vibration design, making it ideal for high-cycle industrial automation. Its anodized aluminum body resists chemical corrosion in harsh environments. The dual-color LED status indicator enables quick diagnostics. Requires ISO 8573-1:2010 Class 4 compressed air (max 50mg/m³ oil content).
- Pneumatic cylinder sequencing in assembly lines
- Clamping/unclamping mechanisms in CNC machinery
- Plastic injection molding machine actuators
- Material handling systems with frequent duty cycles
- Electroplating equipment requiring chemical resistance
Installation guidelines:
Mount in any orientation but avoid downward-facing coil positions.
Use flexible tubing for vibration isolation. Lubricate air supply
with ISO VG32 turbine oil if cycle rate exceeds 5Hz continuously.
| Property | Property Value |
|---|---|
| sku | ESV220B |
| Standard Voltage | DC24V |
