Airtac ESV Solenoid Valve ESV220C
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220C 5/2-Way Solenoid Valve Technical Specifications
- Model: ESV220C
- Valve type: 5/2-way single solenoid (double pilot)
- Port thread: G1/4" (BSPP) with NPT optional
- Effective area: 22mm² (pilot orifice)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage tolerance: ±10% (DC/AC)
- Voltage variants: DC12V/24V, AC24V/110V/220V
- Coil insulation class: F (155℃)
- Response time: ≤15ms (at 0.5MPa)
- Ambient temperature: -5℃ to 80℃ (non-freezing)
- Fluid temperature: 0-60℃
- Seal material: HNBR (Hydrogenated Nitrile)
- Body material: Die-cast aluminum (anodized)
- Porting pattern: ISO 5599-1 standard
- Weight: 340g ±5% (without connector)
- Dimensions: 80mm(L) × 50mm(W) × 65mm(H)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Manual override: Optional paddle actuator
- Cycle life: ≥10 million operations
High-flow proportional solenoid valve with zero-pressure differential start capability, featuring anti-vibration coil design and surge protection circuitry. Optimized for high-frequency switching applications requiring precise directional control. Includes LED status indicator and meets ISO 13849-1 safety requirements. Requires 5μm filtration with automatic drain.
- CNC machine tool changers
- Plastic injection molding machines
- Automated welding positioners
- Lithium battery production lines
- Semiconductor wafer handling robots
- Textile machinery tension control
Operational guidelines:
Maintain air dryness (pressure dew point ≥3℃ below ambient).
Lubricate with ISO VG32 turbine oil if required.
For vertical installation, orient coil upward.
Minimum 500-hour maintenance interval recommended.
| Property | Property Value |
|---|---|
| sku | ESV220C |
| Standard Voltage | AC 110V |
