Airtac ESV Solenoid Valve ESV220CI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220CI Solenoid Valve Technical Specifications
- Model: ESV220CI
- Type: 5/2-way single solenoid (pilot-operated)
- Body material: Anodized aluminum alloy
- Seal material: NBR/FKM optional
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Voltage tolerance: ±10%
- Voltage options: DC24V(2.8W), AC110V(3.5VA), AC220V(3.5VA)
- Response time: ≤20ms (energize), ≤30ms (de-energize)
- Protection rating: IP65 (coil), IP40 (valve body)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow capacity: CV 1.8 (Kv 1.55) at 0.5 MPa
- Weight: 650g ±5% (excluding accessories)
- Dimensions: 120mm(L) × 50mm(W) × 80mm(H)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
High-flow proportional control valve with manual override capability, featuring dust-tight epoxy-coated coil and corrosion-resistant construction. The optimized spool design achieves 20% faster response than standard models. Requires 5μm filtered lubricated air (ISO 8573-1 class 3). Compatible with ISO 15407-1 mounting interfaces.
- High-speed packaging machinery sequencing
- Automated assembly line actuators
- Plastic injection molding clamp control
- CNC machine tool chuck operation
- Beverage filling system pneumatics
Installation guidelines:
Mount with vibration-damping brackets in environments exceeding 0.5G vibration.
Maintain ambient temperature below 60℃ with 10mm clearance around coil.
Use M5x12 stainless steel screws (torque ≤1.2N·m) for manifold mounting.
| Property | Property Value |
|---|---|
| sku | ESV220CI |
| Standard Voltage | AC 110V |
