Airtac ESV Solenoid Valve ESV220F
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220F 5/2-Way Solenoid Valve Technical Details
- Model: ESV220F
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Flow capacity: 1800 Nl/min (Cv=2.3)
- Weight: 320g ±5% (without connectors)
- Dimensions: 52mm(L) × 45mm(W) × 65mm(H)
- Seal materials: NBR standard (FKM/Viton optional)
- Temperature tolerance: -5℃ to 80℃ (23℉ to 176℉)
- Power consumption: ≤2.5W (DC) / ≤4.5VA (AC)
- Response time: ≤30ms (actuation), ≤50ms (release)
- Protection class: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve with dual-coil latching design for bistable control applications. Features corrosion-resistant anodized aluminum body and hardened stainless steel core tube. Optimized for 50% duty cycle operation with manual override capability (push-button actuator included). Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 4.4.2).
- Pneumatic cylinder position control in robotic arms
- High-speed packaging machine sequencing systems
- Injection molding machine clamp mechanisms
- Automotive assembly line fixture controls
- Food processing equipment with washdown requirements
Installation guidelines:
Mount in vibration-free environment using M5 mounting brackets (not included).
Maintain minimum 15mm clearance for heat dissipation. Use 24AWG shielded cables
for electrical connections. Perform monthly air path blow-down maintenance.
| Property | Property Value |
|---|---|
| sku | ESV220F |
| Standard Voltage | DC12V |
