Airtac ESV Solenoid Valve ESV220FI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV220FI High-Flow Solenoid Valve Technical Details
- Model: ESV220FI (ISO 15407-1 compliant)
- Type: 5/3-way double solenoid, center closed position
- Port size: G1/4" (BSPP thread standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 3.5W (DC), 4.2VA (AC)
- Flow capacity: CV 2.8 (Kv 2.4) at 7 bar
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 86mm(L) × 35mm(W) × 54mm(H)
- Seal materials: HNBR main seals, FKM wipers
- Temperature range: -10℃ to 80℃ (non-freezing operation)
- Protection class: IP67 (dustproof/water immersion resistant)
- Service life: ≥10 million cycles (at rated conditions)
- Porting pattern: ISO 5599-1 compliant
Industrial-grade proportional control valve featuring triple-position control with precision spool guidance system. The ESV220FI combines high flow rates with energy-efficient operation through optimized magnetic circuit design. Its aluminum alloy body with hard anodized treatment resists chemical corrosion in harsh environments. Includes LED status indicator and surge protection circuitry.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers requiring mid-stroke positioning
- Test bench pressure regulation systems
- Food processing equipment (oil/water-resistant version available)
Installation guidelines:
Mount in vibration-free location using M5 mounting screws (not included).
Maintain ambient temperature below 60℃ with 20mm clearance around coil.
Use 5μm filtration with automatic drain for optimal performance.
For vertical mounting, position electrical connector upward.
| Property | Property Value |
|---|---|
| sku | ESV220FI |
| Standard Voltage | DC12V |
