Airtac ESV Solenoid Valve ESV230CAI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CAI 5/2-Way Solenoid Valve Specifications
- Model: ESV230CAI
- Type: 5/2-way single solenoid controlled (monostable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Weight: 350g ±5% (without connectors)
- Dimensions: 70mm(L) × 50mm(W) × 100mm(H)
- Seal material: NBR (standard), FKM available for high-temp
- Temperature range: -5℃ to 60℃ (23℉ to 140℉)
- Response time: ≤20ms (at 0.5MPa)
- Flow rate: 750 Nl/min (Cv=1.3)
- Port thread depth: 12mm (minimum engagement)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Service life: ≥10 million cycles (under rated conditions)
High-flow solenoid valve with manual override and LED status indicator. Features brass body with hard anodized aluminum core for corrosion resistance in humid environments. Designed for double-acting cylinder control with zero pressure differential start capability. Includes surge suppression circuit for enhanced coil durability.
- Automated production line actuators
- Plastic injection molding machines
- Textile machinery cylinder control
- Robotic arm positioning systems
- CNC tool changers
- Packaging machine clamp controls
Installation requirements:
- Use 40μm filter with auto-drain (oil mist lubrication recommended)
- Allow ≥30mm clearance below valve for manual override access
- Mount in vibration <5m/s² environments (anti-vibration kit optional)
Maintains stable operation at 85% relative humidity. Compatible with ISO 8573-1:2010 [2:4:2] compressed air quality. For continuous operation, maintain ambient temperature below 50℃ with adequate airflow.
| Property | Property Value |
|---|---|
| sku | ESV230CAI |
| Standard Voltage | AC 110V |
