Airtac ESV Solenoid Valve ESV230CB
$111.63
Regular price
$119.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ESV230CB
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Sleek appearance with compact design;
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm clearance above valve for heat dissipation.
Use shielded cables for feedback signals in EMI-sensitive applications.
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CB Solenoid Valve Specifications
- Model: ESV230CB
- Type: 5/3-way closed center (double solenoid, spring return)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 680g ±5%
- Dimensions: 112mm(L) × 45mm(W) × 65mm(H)
- Flow rate: 750 L/min (ANR)
- Seal material: Heat-resistant NBR (up to 120℃)
- Temperature range: -5℃ to 80℃ (with silicone seals optional for -20℃)
- Power consumption: 4.8W (DC24V), 5.5VA (AC)
- Response time: ≤35ms (exhaust to center)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (full thread engagement recommended)
High-flow proportional control valve with dual coil redundancy and position feedback capability. Features anti-vibration design with copper-alloy plunger and stainless steel spring. Compatible with ISO 15407-1 standards. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
Typical Applications:
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position hold requirements
- Battery production vacuum/pressure control
- Test bench sequencing circuits
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm clearance above valve for heat dissipation.
Use shielded cables for feedback signals in EMI-sensitive applications.
| Property | Property Value |
|---|---|
| sku | ESV230CB |
| Standard Voltage | AC 110V |
