Airtac ESV Solenoid Valve ESV230CBW
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CBW 5/3-Way Solenoid Valve Technical Specifications
- Model: ESV230CBW (Center Closed Configuration)
- Valve type: 5/3-way, double solenoid with spring return
- Port size: PT3/8 (G3/8 ISO228-1 compliant)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Weight: 590g ±2% (including coil and connectors)
- Dimensions: 100mm(L) × 52mm(W) × 45mm(H)
- Body material: Die-cast aluminum alloy (surface anodized)
- Seal materials: NBR (standard), optional FKM/Viton
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Power consumption: 2.5W (DC24V), 4.5VA (AC)
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Protection rating: IP65 (coil), IP40 (valve body)
- Flow capacity: 850 l/min (Cv=1.3 at 0.5MPa)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional solenoid valve with center-blocked mid-position, engineered for precision directional control in industrial automation. Features dual manual overrides, surge protection diodes, and anti-vibration coil design. The optimized flow path reduces pressure drop by 18% compared to previous generation models. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Pneumatic cylinder sequencing in automotive assembly lines
- Clamping/positioning systems in CNC machinery
- Material handling equipment with multi-position actuators
- Packaging machine indexer control systems
- Plastic injection molding machine air circuits
Installation guidelines:
Mount in vibration-free location using M5 mounting bolts (max torque 3.5Nm).
Maintain 20mm clearance below valve for manifold heat dissipation.
Lubricate using ISO VG32 turbine oil if air line lubrication is required.
| Property | Property Value |
|---|---|
| sku | ESV230CBW |
| Standard Voltage | AC 110V |
