Airtac GA Manifold Block GA20006
2. Compatible with multiple mounting brackets for flexible configuration with regulators and lubricators. Available bracket types: T-style, L-style, U-style.
Category: Air Distribution Block | Brand: AIRTAC | Series: GA
AirTAC GA Series Manifold GA20006 Technical Details
- Model: GA20006 (5-station manifold block)
- Type: Modular aluminum air distribution block
- Port configuration: 1/4" NPT inlet, 5×1/8" NPT outlets
- Material: Anodized aluminum alloy (AL6063-T5)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 450 NL/min
- Temperature range: -20℃ to 80℃
- Surface hardness: HV 120±15
- Weight: 380±10g
- Dimensions: 150mm(L) × 32mm(W) × 32mm(H)
- Mounting: DIN rail compatible (TS35/7.5/15)
- Seal type: Integrated NBR O-rings
- Corrosion resistance: 500hr salt spray tested
Multi-channel pneumatic distribution block engineered for modular system layouts. Features precision-machined internal passages (Ø3.5mm) with optimized flow characteristics. The hard-anodized surface resists scratches during tool changes, while the symmetrical design allows bidirectional piping. Compatible with ISO 15407-1 standard subplates.
- Multi-cylinder pneumatic control systems
- Automated assembly line tooling stations
- Plastic injection molding machine air circuits
- Textile machinery air distribution networks
- Semiconductor handling equipment clusters
Installation protocol:
Apply 2-3Nm torque during mounting. Use PTFE tape on NPT threads.
For multi-block configurations, maintain 1.5mm gap between units for thermal expansion.
Perform monthly blow-down of sediment ports.
| Property | Property Value |
|---|---|
| sku | GA20006 |
| Port Size | PT1/8 |
