Airtac GAL Lubricator GAL20008J
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL20008J
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation protocol:
Mount vertically downstream of filters/regulators. Prime by rotating adjustment knob
clockwise until oil appears in sight glass, then set to 3-5 drops/m³ airflow.
Replace bowl every 2 years or 10,000 cycles.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL20008J Lubricator Specifications
- Model: GAL20008J
- Type: Automatic micro-drip oil feeder
- Capacity: 2000ml (polycarbonate reservoir)
- Oil viscosity: ISO VG32 or equivalent (mineral-based)
- Operating pressure: 0.05–1.0 MPa
- Connection port: PT1/8 (BSPP thread)
- Flow adjustment: 0-120 drops/min (rotary dial)
- Body material: Anodized aluminum alloy
- Transparency: ≥85% visible oil level
- Temperature range: 5℃ to 60℃
- Weight: 0.82kg (with full reservoir)
- Dimensions: 98mm(H) × 80mm(D) × 130mm(W)
- Drip window: 16mm diameter borosilicate glass
Precision pneumatic line lubricator featuring anti-clog needle valve and corrosion-resistant internals. The dual-chamber design maintains consistent oil supply during refills. Integrated check valve prevents backflow contamination. Requires ISO cleanliness code 18/16/12 compressed air.
Typical Applications:
- Pneumatic cylinder maintenance systems
- Assembly line air tool lubrication
- Packaging machine rotary joints
- Food processing pneumatic actuators (food-grade oil compatible)
- Textile machinery air preparation units
Installation protocol:
Mount vertically downstream of filters/regulators. Prime by rotating adjustment knob
clockwise until oil appears in sight glass, then set to 3-5 drops/m³ airflow.
Replace bowl every 2 years or 10,000 cycles.
| Property | Property Value |
|---|---|
| sku | GAL20008J |
| Port Size | PT1/4 |
