Airtac GAL Lubricator GAL200C06
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200C06 Oil Lubricator Specifications
- Model: GAL200C06
- Type: Micro-lubrication regulator with transparent bowl
- Flow capacity: 30-120 cm³/min (adjustable)
- Oil cup capacity: 200 cm³
- Operating pressure: 0.3-1.0 MPa
- Port size: PT1/4 (BSPP thread)
- Viscosity range: 20-500 cSt (ISO VG22~VG460)
- Body material: Anodized aluminum alloy
- Bowl material: Polycarbonate (PC)
- Temperature range: 0℃ to 60℃ (non-freezing)
- Weight: 480g ±5% (empty), 680g ±5% (filled)
- Dimensions: 155mm(H) × 80mm(W) × 80mm(D)
- Drip window: 360° rotatable observation port
- Mounting: Standard 35mm DIN rail or bracket
Precision oil-fog lubricator featuring anti-clog needle valve adjustment and visual oil level monitoring. The dual-chamber design ensures stable oil supply during pressure fluctuations. Compatible with most pneumatic oils (excluding ester-based fluids). Includes built-in check valve to prevent backflow.
- Pneumatic cylinder maintenance systems
- Air tool lubrication stations
- Packaging machine chain lubrication
- Textile machinery pneumatic circuits
- Automated assembly line lubrication points
Installation note:
Mount vertically within 5 meters downstream of air compressor.
Adjust drip rate under actual operating pressure - initial setting:
1 drop/5-10 cycles. Replace oil annually or after 150 operating hours.
| Property | Property Value |
|---|---|
| sku | GAL200C06 |
| Port Size | PT1/8 |
