Airtac GAL Lubricator GAL200C06J
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200C06J Automatic Lubricator Specifications
- Model: GAL200C06J
- Type: Micro-drop automatic lubricator (pressure-balanced)
- Capacity: 200ml transparent oil reservoir
- Material: Aluminum alloy body with polycarbonate sight glass
- Port size: PT1/4 (G1/4 adaptor available)
- Operating pressure: 0.2–0.7 MPa
- Oil viscosity range: ISO VG32–VG220 (mineral oil)
- Drip rate adjustment: 0–3 drops/min (calibrated knob)
- Temperature range: -10℃ to 60℃
- Weight: ~450g (empty), 650g (filled)
- Dimensions: 120mm(H) × 85mm(W) × 85mm(D)
- Mounting orientation: Vertical ±15°
- Air consumption: ≤0.05MPa pressure drop at max flow
- Protection rating: IP40 (dust-protected)
Precision pneumatic line lubricator featuring visual oil monitoring and stepless flow regulation. The dual-chamber design maintains consistent lubrication under fluctuating air pressures. Integrated anti-clog nozzle ensures reliable operation in high-cycling applications (up to 10 million cycles). Compatible with most pneumatic tools requiring ISO cleanliness level 18/16/2.
- Pneumatic actuator maintenance systems
- Industrial air compressor downstream lubrication
- Automated assembly line tooling
- Packaging machinery cylinder lubrication
- CNC machine pneumatic circuits
Installation protocol:
Install downstream of FRL units with minimum 300mm straight piping before lubricator.
Prime system by rotating adjustment knob fully clockwise for 30 seconds before fine-tuning.
Replace desiccant cartridge every 6 months in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GAL200C06J |
| Port Size | PT1/8 |
