Airtac GAL Lubricator GAL200C08
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200C08 Automatic Lubricator Specifications
- Model: GAL200C08
- Type: Micro-drip oil feeder with transparent reservoir
- Capacity: 200ml
- Oil output adjustment: 1-60 drops/min (0.01-0.6 ml/min)
- Operating pressure range: 0.2-1.0 MPa
- Port connection: PT1/8 (BSPP thread)
- Body material: Anodized aluminum alloy
- Oil cup material: Impact-resistant polycarbonate
- Weight: 350g ±5% (empty)
- Dimensions: 120mm(H) × 80mm(W) × 45mm(D)
- Operating temperature: 5℃ to 60℃
- Viscosity range: ISO VG32-220 (15-320 cSt)
- Drip window material: Borosilicate glass
- Pressure resistance: 1.5 MPa burst pressure
Precision pneumatic line lubricator featuring a triple-stage filtration system (40μm metal mesh + 25μm sintered bronze + 10μm nylon filter). The dual-chamber design allows continuous oil supply without system shutdown. Includes anti-drainback valve and visual oil level indicator with MAX/MIN markers. Calibrated adjustment knob provides repeatable flow settings.
- Pneumatic tool lubrication systems
- Production line cylinder maintenance
- Packaging machine air circuit protection
- Robotic actuator lubrication stations
- CNC machine pneumatic components
Installation protocol:
Mount vertically downstream of FRL units. Prime the unit by rotating adjustment knob fully clockwise before initial use.
Replace oil when level drops below 20% capacity. Compatible with ISO VG32 turbine oil or equivalent non-detergent lubricants.
| Property | Property Value |
|---|---|
| sku | GAL200C08 |
| Port Size | PT1/4 |
