Airtac GAL Lubricator GAL200N06J
$24.62
Regular price
$32.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL200N06J
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation note:
Mount vertically upstream of FRL units, 500mm minimum from actuators.
Adjust oil flow after 30-min system pressurization. Replace oil annually
or after 1,800hrs operation. Use bypass valve during initial filling.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200N06J Automatic Lubricator Specifications
- Model: GAL200N06J
- Type: Micro-fog automatic oil feeder
- Capacity: 200ml (transparent reservoir)
- Operating pressure: 0.05-1.0 MPa
- Oil output: 5-60 drops/min (adjustable)
- Port size: PT1/4 (G1/4 optional)
- Body material: Aluminum alloy (anodized)
- Reservoir material: Polycarbonate
- Seal material: NBR
- Temperature range: 5℃ to 60℃
- Weight: 480g ±5% (empty)
- Dimensions: 132mm(H) × 76mm(Dia)
- Viscosity range: ISO VG32-220 (68-1000 SUS)
- Air consumption: <0.1 Nl/min (idle)
Precision oil mist lubricator with visible oil level and corrosion-resistant construction. Features drip window observation and anti-clog nozzle design. Requires ISO cleanliness code 18/16/13 compressed air. Includes built-in check valve to prevent backflow.
Typical Applications:
- Pneumatic tool maintenance systems
- CNC machine air line lubrication
- Assembly line pneumatic component networks
- Textile machinery actuator lubrication
- Food processing air line systems (food-grade oil compatible)
Installation note:
Mount vertically upstream of FRL units, 500mm minimum from actuators.
Adjust oil flow after 30-min system pressurization. Replace oil annually
or after 1,800hrs operation. Use bypass valve during initial filling.
| Property | Property Value |
|---|---|
| sku | GAL200N06J |
| Port Size | PT1/8 |
