Airtac GAL Lubricator GAL200N08
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL200N08 Automatic Lubricator Specifications
- Model: GAL200N08
- Type: Micro-drip automatic oil feeder (pneumatic operation)
- Capacity: 200ml (transparent polycarbonate reservoir)
- Operating pressure range: 0.15–0.8 MPa
- Oil output adjustment: 1-3 drops/min (rotary dial with 15-click precision)
- Inlet/Outlet ports: PT1/4 (G1/4 optional)
- Weight: 520g ±10g (empty)
- Dimensions: 98mm(H) × 82mm(W) × 152mm(D)
- Body material: Anodized aluminum alloy
- Seal material: HNBR oil-resistant rubber
- Operating temperature: -10℃ to +60℃
- Viscosity range: ISO VG32–VG68 (22–68 cSt at 40℃)
- Orientation requirement: Vertical mounting (±5° tolerance)
High-precision pneumatic lubricator featuring anti-clog drip visualization and tool-free calibration. The dual-chamber design prevents oil backflow during pressure fluctuations. Integrated mounting bracket allows 180° rotation for flexible installation. Requires ISO cleanliness code 18/16/13 compressed air.
- Pneumatic tool lubrication in assembly lines
- Continuous lubrication for cylinder-piston systems
- Packaging machinery chain drives
- Textile machine air actuator maintenance
- CNC machine pneumatic circuit protection
Operation guidance:
Prime the lubricator by rotating the red knob counterclockwise until oil appears in the sight glass.
Maintain 30-50% oil level for optimal pressure balance. Replace filter element (MF-04) every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | GAL200N08 |
| Port Size | PT1/4 |
