Airtac GAL Lubricator GAL30008
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL30008 Automatic Lubricator Specifications
- Model: GAL30008 (GAL Series)
- Type: Micro-droplet oil feed device with transparent reservoir
- Capacity: 300cc (Polycarbonate oil cup)
- Operating pressure range: 0.2-1.0 MPa
- Oil flow adjustment: 0.5-2.0 drops/min (precision needle valve control)
- Applicable oils: ISO VG32 or equivalent turbine oil (DIN51502)
- Weight: 310g ±5% (empty reservoir)
- Dimensions: 82mm(L) × 52mm(W) × 128mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM)
- Temperature range: 0℃ to 60℃ (non-freezing environment)
- Inlet/Outlet ports: Rc1/4 (BSPP 1/4")
- Orientation: Vertical installation required (±5° tolerance)
Precision oil mist lubricator featuring bubble-through observation window and corrosion-resistant construction. Equipped with a 360° rotatable bowl for flexible installation. The dual-stage filtration system includes 40μm mesh and sintered bronze element. Requires periodic bowl cleaning every 3-6 months depending on oil purity.
- Pneumatic cylinder maintenance in automated assembly lines
- Air tool lubrication in automotive manufacturing
- Packaging machinery chain drive systems
- Textile machine air actuator preservation
- Semiconductor production equipment
Installation protocol:
Mount upstream of FRL units with downward-facing oil bowl. Prime the system by manually rotating the adjustment knob clockwise until oil appears in the sight glass. Maintain oil level between 30-80% of reservoir capacity.
Compatibility note:
Not suitable for synthetic ester-based oils or fluids with phosphate additives. Maximum viscosity: 150 SUS at 100°F. Always bleed air pressure before refilling.
| Property | Property Value |
|---|---|
| sku | GAL30008 |
| Port Size | PT1/4 |
