Airtac GAL Lubricator GAL300C08
$30.20
Regular price
$37.70
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL300C08
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Maintenance protocol:
Replace oil monthly under continuous operation. Always maintain oil level between 1/3 and 2/3 capacity.
Use only recommended ISO VG32 or equivalent turbine oil. For cold environments (＜10℃), pre-mix with 20% kerosene.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300C08 Lubricator Technical Specifications
- Model: GAL300C08 (GAL Series)
- Type: Micro-drip adjustable oil feeder
- Oil capacity: 300ml transparent reservoir
- Oil output adjustment: 0.01-0.06ml/cycle (30° rotation per 0.01ml)
- Operating pressure: 0.2-1.0 MPa
- Connection port: Rc1/8 (BSPP 1/8")
- Body material: POM (Polyoxymethylene)
- Oil cup material: Impact-resistant PC
- Temperature range: 5℃ to 60℃
- Weight: 420g ±5% (empty)
- Dimensions: 152mm(H) × Φ76mm(Diameter)
- Viscosity range: ISO VG32-68 (optimal performance)
- Drip visibility: 360° observable oil window
- Mounting orientation: Vertical installation required
- Protection rating: IP40 (dust protected)
Precision lubricator with visual flow monitoring, featuring twist-lock oil bowl design for spill-free maintenance. The dual-stage filtration system includes 80μm primary mesh and 25μm secondary filter. Anti-drain check valve prevents oil backflow during system depressurization.
Typical Applications:
- Pneumatic cylinder lubrication systems
- Air tool maintenance stations
- Packaging machine pneumatic circuits
- Textile machinery air preparation units
- Automated assembly line FRL units
Maintenance protocol:
Replace oil monthly under continuous operation. Always maintain oil level between 1/3 and 2/3 capacity.
Use only recommended ISO VG32 or equivalent turbine oil. For cold environments (＜10℃), pre-mix with 20% kerosene.
| Property | Property Value |
|---|---|
| sku | GAL300C08 |
| Port Size | PT1/4 |
