Airtac GAL Lubricator GAL300N08J
$29.06
Regular price
$36.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GAL300N08J
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The drip oil structure employs a gap-sealing mechanism, ensuring more stable and reliable lubrication adjustment;
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
Installation protocol:
Mount downstream of FRL units (after pressure regulator), maintain vertical position,
and refill when oil level reaches 20% capacity. Use only non-detergent R&O oils.
2. Featuring a single-rotation oil adjustment ring with linear flow distribution, allowing approximate oil delivery estimation through calibrated scale positioning;
3. Specially designed nozzle configuration generates negative pressure at the outlet, achieving minimal mist generation at low flow rates;
4. Supports non-stop oil replenishment with high-capacity reservoir;
5. Multiple cup material options (PC, metal, nylon) available for diverse environmental requirements;
6. Compatible with fixed bracket mounting solutions.
Category: Lubricators | Brand: Airtac | Series: GAL
AirTAC GAL300N08J Lubricator Specifications
- Model: GAL300N08J
- Type: Micro-fog automatic lubricator
- Capacity: 300ml (transparent polycarbonate reservoir)
- Connection size: PT1/8 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Oil output adjustment: 5-120 drops/min (rotary dial control)
- Body material: Anodized aluminum alloy
- Seal material: Viton® FKM (fluorocarbon rubber)
- Temperature range: 5℃ to 60℃ (operating fluid temp)
- Weight: 480g ±5% (empty), 780g ±5% (filled)
- Dimensions: 98mm(H) × 75mm(D) × 75mm(W)
- Viscosity range: ISO VG32–VG68 (22–320 cSt at 40℃)
- Orientation: Vertical installation required (±5° tolerance)
Precision pneumatic lubricator with visual oil level indicator and corrosion-resistant construction. Features drip window observation port and tool-free refill cap. Includes anti-clog nozzle design for consistent oil mist delivery. Requires ISO Class 4/3/2 compressed air (ISO 8573-1).
Typical Applications:
- Pneumatic cylinder maintenance systems
- Air tool lubrication in automotive assembly lines
- Packaging machinery chain lubrication
- Textile machine pneumatic component protection
- Industrial robot end-effector maintenance
Installation protocol:
Mount downstream of FRL units (after pressure regulator), maintain vertical position,
and refill when oil level reaches 20% capacity. Use only non-detergent R&O oils.
| Property | Property Value |
|---|---|
| sku | GAL300N08J |
| Port Size | PT1/4 |
