Airtac GPF Oil Mist Separator GPF20008AD
2、Selectable filtration accuracy: 0.3μm or 0.01μm micron ratings;
3、Two configurations available: Integrated differential pressure/manual operation or automatic drainage systems;
4、Bowl materials include polycarbonate (PC), nylon, and metal options for diverse environmental compatibility;
5、Single-unit models support fixed bracket mounting, while modular assemblies integrate seamlessly with AIRTAC triple/double units.
Category: Oil Mist Separators | Brand: AIRTAC | Series: GPF
AirTAC GPF Oil Mist Separator GPF20008AD Technical Details
- Model: GPF20008AD
- Type: Multi-stage centrifugal + filter element
- Flow capacity: 200 L/min (at 0.7MPa)
- Filtration efficiency: ≥99.5% for 0.3μm particles
- Operating pressure: 0.15–1.0 MPa
- Max pressure: 1.5 MPa
- Connection port: G1/2 (BSPP thread)
- Housing material: Anodized aluminum alloy
- Filter element: Glass fiber reinforced resin
- Weight: 1.8 kg (including mounting bracket)
- Dimensions: 198mm(H) × 120mm(Dia.) × 150mm(Width with bracket)
- Temperature range: 5℃ to 60℃
- Pressure drop: ≤0.02 MPa (at rated flow)
- Oil emission: ≤0.01 mg/m³ (post-filtration)
- Maintenance interval: 4,000–6,000 operating hours
- Drain type: Manual/auto drain optional
- IP rating: IP54 (standard configuration)
High-efficiency coalescing separator designed for compressed air systems, featuring a three-stage purification process: centrifugal pre-separation, multi-layer fiber filtration, and final coalescing. The anti-corrosion housing integrates a visible contamination indicator and tool-free element replacement. Optimized baffle design reduces turbulence for 18% lower pressure loss compared to previous models.
- CNC machine tool lubrication systems
- Pneumatic actuator air preparation units
- Laser cutting machine air filtration
- Food packaging pneumatic lines
- Semiconductor cleanroom air supply
- Dental chair pneumatic systems
Installation guidelines:
Mount vertically within 10 meters downstream of compressors. Install automatic drain below separator with 15° downward slope. Replace indicator's O-ring (AS568-014) annually. Avoid ethanol-based cleaning agents.
| Property | Property Value |
|---|---|
| sku | GPF20008AD |
| Drain Type | Auto Drain |
| Port Size | PT1/4 |
| Bracket Code | With Bracket |
| Cup Material | PC Cup |
| Water Cup Capacity | 19CC |
| Filtration Accuracy | 0.01μm |
