Airtac GPF Oil Mist Separator GPF200C06AJD
2、Selectable filtration accuracy: 0.3μm or 0.01μm micron ratings;
3、Two configurations available: Integrated differential pressure/manual operation or automatic drainage systems;
4、Bowl materials include polycarbonate (PC), nylon, and metal options for diverse environmental compatibility;
5、Single-unit models support fixed bracket mounting, while modular assemblies integrate seamlessly with AIRTAC triple/double units.
Category: Oil Mist Separators | Brand: AIRTAC | Series: GPF
AirTAC GPF Oil Mist Separator GPF200C06AJD Technical Details
- Model: GPF200C06AJD
- Type: Centrifugal + filter element dual-stage separation
- Flow capacity: 200 L/min (at 0.7MPa)
- Filtration efficiency: ≥95% (0.3μm particles)
- Operating pressure: 0.2-1.0 MPa
- Pressure loss: ≤0.02 MPa
- Oil storage capacity: 60ml
- Port connection: Rc3/8 (BSPP)
- Housing material: Aluminum alloy (anodized)
- Filter element: Stainless steel mesh (SUS304)
- Temperature range: -10℃ to 80℃
- Weight: 0.8 kg ±5%
- Dimensions: 160mm(L) × 120mm(W) × 120mm(H)
- Drain type: Manual drain plug with anti-splash design
High-efficiency coalescing separator engineered for compressed air systems, featuring spiral-guided airflow channels that enhance centrifugal separation. The corrosion-resistant construction includes a transparent oil level window for visual monitoring. Compatible with ISO VG32 and most synthetic lubricants.
- CNC machining centers with mist lubrication systems
- Industrial air compressor aftercoolers
- Pneumatic tool exhaust treatment
- Food processing pneumatic lines (requires downstream filters)
- Automotive painting booth air preparation
Maintenance protocol:
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.05MPa.
Always install vertically with arrow mark facing downward. Empty oil reservoir weekly
using the magnetic drain plug to prevent re-entrainment.
| Property | Property Value |
|---|---|
| sku | GPF200C06AJD |
| Drain Type | Auto Drain |
| Port Size | PT1/8 |
| Bracket Code | Without bracket |
| Cup Material | Metal Cup |
| Water Cup Capacity | 19CC |
| Filtration Accuracy | 0.01μm |
