Airtac GPF Oil Mist Separator GPF200C06M
2、Selectable filtration accuracy: 0.3μm or 0.01μm micron ratings;
3、Two configurations available: Integrated differential pressure/manual operation or automatic drainage systems;
4、Bowl materials include polycarbonate (PC), nylon, and metal options for diverse environmental compatibility;
5、Single-unit models support fixed bracket mounting, while modular assemblies integrate seamlessly with AIRTAC triple/double units.
Category: Oil Mist Separators | Brand: AIRTAC | Series: GPF
AirTAC GPF Oil Mist Separator GPF200C06M Technical Specifications
- Model: GPF200C06M
- Type: Multi-stage coalescing filter with automatic drainage
- Flow capacity: 200 L/min (at 0.7MPa)
- Filtration grade: 0.3 μm residual oil content ≤0.01 ppm
- Operating pressure: 0.15–1.0 MPa
- Max pressure: 1.5 MPa
- Inlet/Outlet thread: G1/2" (BSPP)
- Drain port thread: Rc1/8"
- Filter element material: Borosilicate glass fiber
- Housing material: Anodized aluminum alloy
- Temperature range: 5℃ to 60℃
- Initial pressure drop: ≤0.02 MPa
- Weight: 1.8 kg (dry), 2.1 kg (with standard oil)
- Dimensions: 165mm(Ø) × 280mm(H)
- Optional accessories: Pressure gauge kit (PG-06M), mounting bracket (MB-200)
- Compliance: ISO 8573-1 Class 1.4.1
High-efficiency coalescing separator designed for industrial compressed air systems, featuring three-stage filtration: centrifugal pre-separation, depth coalescing matrix, and final activated carbon layer. The anti-re-entrainment design prevents oil carryover with 99.999% efficiency at 25℃. Maintenance indicators include visual bowl inspection window and differential pressure warning sticker (color change at ΔP≥0.1MPa).
- CNC machine tool spindle air-oil lubrication systems
- Laser cutting machine optical lens protection
- Pharmaceutical blow-fill-seal (BFS) equipment
- Automotive painting robots air preparation
- Semiconductor cleanroom pneumatic networks
Installation protocol:
Mount vertically downstream of refrigerated dryers (minimum 3m distance from compressor).
Replace element every 8,000 hours or when pressure drop exceeds 0.15MPa.
Weekly manual drainage required for systems with intermittent operation.
| Property | Property Value |
|---|---|
| sku | GPF200C06M |
| Drain Type | Differential Pressure + Manual Drain |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Cup Material | Metal Cup |
| Water Cup Capacity | 19CC |
| Filtration Accuracy | <0.3μm> |
