Airtac GPFR Pressure Regulating Precision Filter GPFR20006ALJD
$68.82
Regular price
$76.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GPFR20006ALJD
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Snap-on cap pressure gauge design saves installation space while featuring a magnified dial with clear legible scales;
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Replace filter element every 6-12 months depending on air quality.
Adjust pressure only when downstream flow is stopped.
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR Precision Filter Regulator GPFR20006ALJD Technical Details
- Model: GPFR20006ALJD
- Type: Combined filter regulator with pressure gauge
- Port size: PT1/4 (BSPP thread)
- Filtration grade: 5 μm (replaceable element)
- Maximum pressure: 1.5 MPa
- Adjustment range: 0.05–0.85 MPa
- Flow capacity: 2000 NL/min
- Body material: Aluminum alloy (anodized)
- Bowl material: Polycarbonate (impact-resistant)
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual drain with anti-spray shield
- Gauge diameter: 40mm (chrome-plated brass)
- Weight: 480g ±5% (without packaging)
- Dimensions: 105mm(H) × 55mm(W) × 85mm(D)
- Pressure gauge error: ±2.5% F.S.
Industrial-grade combination unit integrating filtration, pressure regulation, and visual monitoring. Features dual-chamber design with automatic pressure locking mechanism and splash-proof drain. The transparent bowl allows visual inspection of filter contamination levels.
Typical Applications:
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Automated assembly line pressure control
- Food processing pneumatic actuators
- Medical equipment air purification stages
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Replace filter element every 6-12 months depending on air quality.
Adjust pressure only when downstream flow is stopped.
| Property | Property Value |
|---|---|
| sku | GPFR20006ALJD |
| Port Size | PT1/8 |
