Airtac GPFR Pressure Regulating Precision Filter GPFR20006ALJNM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006ALJNM Precision Regulating Filter Specifications
- Full model code: GPFR20006ALJNM
- Type: Combination filter regulator with pressure gauge
- Port size: PT1/4 (BSP 1/4 female threads)
- Max operating pressure: 1.5 MPa
- Adjustable pressure range: 0.05-0.85 MPa
- Flow capacity: 2500 NL/min (ANR)
- Filtration grade: 5μm (with auto-drain)
- Filter bowl capacity: 14.5 cm³
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: NBR + POM composite
- Ambient temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 480g ±3% (including gauge)
- Dimensions: 132mm(H) × 52mm(W) × 86mm(D)
- Gauge diameter: 40mm (liquid-filled dual-scale 0-1MPa/0-150PSI)
- Pressure adjustment: Lockable rotary knob with ±2% accuracy
Professional-grade combination unit integrating 3-stage filtration (centrifugal separation, sintered bronze filter, and mist elimination) with precision pressure regulation. Features a shock-resistant glycerin-filled gauge and anti-backspin adjustment knob. The transparent polycarbonate bowl with safety guard allows visual debris monitoring and provides 180° rotation for flexible installation.
- CNC machine pneumatic control systems
- Semiconductor manufacturing equipment
- Automated packaging line air preparation
- Laser cutting machine air supply
- Pharmaceutical production pneumatic circuits
Installation protocol:
Mount vertically with downward-facing drain port. Install upstream of lubricators in FRL systems.
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.1MPa.
Bowl torque specification: 3.5-4.0 N·m during maintenance.
| Property | Property Value |
|---|---|
| sku | GPFR20006ALJNM |
| Port Size | PT1/8 |
