Airtac GPFR Pressure Regulating Precision Filter GPFR20006ALNM
$63.96
Regular price
$71.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GPFR20006ALNM
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Snap-on cap pressure gauge design saves installation space while featuring a magnified dial with clear legible scales;
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
Maintenance protocol:
Replace bowl every 5,000 hours or when moisture reaches MAX line.
Lubricate regulator stem quarterly with ISO VG32 turbine oil.
Always depressurize before disassembly.
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006ALNM Precision Regulating Filter Specifications
- Model: GPFR20006ALNM
- Type: Combined pressure regulator with 40μm filtration
- Port size: PT1/2 (BSPP thread)
- Max flow rate: 3,500 L/min (ANR)
- Operating pressure range: 0.05–1.0 MPa
- Pressure regulation accuracy: ±0.02 MPa
- Filter element grade: 40μm (5μm optional with different cartridge)
- Water removal efficiency: ≥80% (at 0.7MPa)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Weight: 1.25 kg (including mounting bracket)
- Dimensions: 152mm(H) × 68mm(W) × 88mm(D)
- Drain type: Semi-automatic float drain
- Pressure gauge interface: G1/8 (optional gauge included)
- Mounting: Panel or bracket (360° rotatable)
Two-stage filtration regulator combining 40μm particulate removal and coalescing filtration with precision pressure stabilization. Features a visible bowl with anti-static coating and manual blowdown button. The dual-chamber design maintains consistent downstream pressure during filter element replacement.
Typical Applications:
- CNC machine tool pneumatic systems
- Automated assembly line air preparation
- Laser cutting machine air knife controls
- Food packaging equipment (FDA-compliant version available)
- Semiconductor manufacturing cleanrooms
Maintenance protocol:
Replace bowl every 5,000 hours or when moisture reaches MAX line.
Lubricate regulator stem quarterly with ISO VG32 turbine oil.
Always depressurize before disassembly.
| Property | Property Value |
|---|---|
| sku | GPFR20006ALNM |
| Port Size | PT1/8 |
