Airtac GPFR Pressure Regulating Precision Filter GPFR20006ASJM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006ASJM Precision Regulating Filter Specifications
- Model: GPFR20006ASJM
- Type: Pressure regulating filter with gauge
- Port size: PT1/4 (G1/4 thread)
- Filtration grade: 5 μm (with auto-drain)
- Pressure regulation range: 0.05–0.95 MPa
- Max operating pressure: 1.5 MPa
- Flow capacity: 2000 NL/min
- Weight: ~680g (including mounting bracket)
- Dimensions: 130mm(L) × 70mm(W) × 70mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Condensate capacity: 1.5cc (bowl volume)
- Pressure gauge: 1/8" dial type (0-1.0 MPa scale)
Integrated pressure regulation and filtration unit combining 5μm coalescing filter element with precision pressure control. Features corrosion-resistant aluminum construction, transparent polycarbonate bowl with guard, and tamper-proof adjustment knob. Includes wall-mount bracket and 360° rotatable ports for flexible installation.
- Pneumatic tool air preparation stations
- Packaging machine air line conditioning
- Medical gas pressure regulation systems
- Automated assembly line pneumatic controls
- Food processing equipment (FDA-compliant versions available)
Maintenance protocol:
Replace filter element every 6-12 months depending on moisture load.
Drain bowl daily in high-humidity environments. Use upstream pre-filter
(40μm) for dusty conditions. Maximum vertical mounting angle: ±15°.
| Property | Property Value |
|---|---|
| sku | GPFR20006ASJM |
| Port Size | PT1/8 |
