Airtac GPFR Pressure Regulating Precision Filter GPFR20006LJD
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006LJD Precision Air Filter Regulator Specifications
- Model: GPFR20006LJD
- Type: Combined filter regulator with pressure gauge
- Filtration grade: 5 μm (0.005mm)
- Maximum pressure: 1.5 MPa (217.5 PSI)
- Flow capacity: 3000 L/min (Cv=2.0)
- Port size: PT3/8" (NPT3/8" optional)
- Filter element: Sintered bronze (stainless steel upgrade available)
- Drain type: Manual drain cup with anti-drip lock
- Pressure adjustment range: 0.05-0.85 MPa
- Operating temperature: -5℃ to 60℃ (non-freezing)
- Weight: 0.8 kg (with bracket)
- Dimensions: 130mm(H) × 70mm(W) × 95mm(D)
- Gauge diameter: 40mm (dual scale bar/kPa)
- Seal material: HNBR (hydrogenated nitrile)
- Housing material: Anodized aluminum alloy
Two-stage conditioning unit combining 360° cyclonic separation filtration and precision pressure regulation. Features dual-chamber design with visible bowl contamination indicator. The integrated dampened gauge reduces needle vibration for stable readings. Optional silencer available for exhaust.
- Pneumatic tool air preparation stations
- Automated assembly line main air lines
- Medical gas control systems (oil-free verification required)
- Food packaging machinery moisture control
- Laser cutting machine air knife supplies
Maintenance protocol:
Drain daily in high-humidity environments. Replace filter element when
pressure drop exceeds 0.05MPa. Use vertical mounting position only.
| Property | Property Value |
|---|---|
| sku | GPFR20006LJD |
| Port Size | PT1/8 |
