Airtac GPFR Pressure Regulating Precision Filter GPFR20006LNM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006LNM Pressure-Regulating Precision Filter Specifications
- Model: GPFR20006LNM
- Type: 3-in-1 combination unit (Filter + Regulator + Lubricator optional)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 1,500 L/min
- Filtration rating: 5 μm (98% efficiency)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa range)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 680 g ±2%
- Dimensions: 165mm(H) × 60mm(W) × 85mm(D)
- Drain type: Manual push-button with anti-splash cover
- Mounting: Bracket slot for 25mm rail or direct panel mounting
Industrial-grade modular filter regulator featuring triple-stage filtration (deflector, sintered bronze, and fiber mesh layers) with moisture separation efficiency >85%. The pressure compensation mechanism maintains ±0.02 MPa stability under fluctuating flows. Optional lubricator version accepts ISO VG32-68 oils with adjustable drip rate (0-15 drops/min).
- Pneumatic tool air preparation stations
- Packaging machinery main air lines
- CNC machine tool pneumatic systems
- Semiconductor manufacturing clean air supply
- Automated assembly line actuators
Maintenance protocol:
Replace filter element every 4,000 operational hours or when pressure drop exceeds 0.1 MPa.
Always install vertically with arrow marking aligned to airflow direction.
Drain condensate daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GPFR20006LNM |
| Port Size | PT1/8 |
