Airtac GPFR Pressure Regulating Precision Filter GPFR20006SD
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006SD Pressure-Regulating Precision Filter Specifications
- Model: GPFR20006SD
- Type: 3-in-1 combination unit (Filter + Regulator + Pressure Gauge)
- Filtration grade: 5μm (98% efficiency)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 1,500 L/min (ANR)
- Port size: PT1/4 (BSPP thread)
- Body material: Die-cast aluminum (anodized finish)
- Bowl material: Polycarbonate (transparent)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual drain with splash guard
- Pressure gauge range: 0–1.6 MPa (swivel type)
- Weight: 580g ±5%
- Dimensions: 130mm(H) × 80mm(W) × 65mm(D)
- Protection rating: IP54 (bowl cover included)
- Vibration resistance: ≤10 Hz @ 1.5mm amplitude
Integrated filtration-regulator unit featuring triple-stage particle separation: centrifugal pre-filter, 5μm sintered stainless steel element, and final baffle filtration. Includes 270° rotatable gauge with shock-resistant liquid-filled display. The ergonomic knob allows ±0.02 MPa pressure regulation accuracy with tactile feedback.
- Pneumatic tool air line conditioning
- Medical gas pressure control systems
- Food processing pneumatic circuits
- Semiconductor manufacturing equipment
- Automated painting systems
- Laboratory instrument air supply
Maintenance note:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.05 MPa.
Always depressurize before bowl removal. Use vertical mounting position (±15° tolerance)
for optimal condensate drainage.
| Property | Property Value |
|---|---|
| sku | GPFR20006SD |
| Port Size | PT1/8 |
