Airtac GPFR Pressure Regulating Precision Filter GPFR20006SJND
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR Pressure-Regulating Precision Filter GPFR20006SJND Technical Details
- Model: GPFR20006SJND
- Type: Integrated pressure regulator + 5μm precision filter
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Max pressure: 1.0 MPa
- Flow capacity: 1,000 L/min (ANR)
- Filter element: Sintered bronze (replaceable)
- Water removal efficiency: ≥80% (ISO 8573-1)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0 MPa scale)
- Bowl capacity: 12 cm³
- Temperature range: -20℃ to 60℃ (non-freezing)
- Body material: Die-cast aluminum (anodized)
- Seal material: HNBR (hydrogenated nitrile)
- Weight: 480g ±5%
- Dimensions: 98mm(H) × 55mm(W) × 82mm(D)
- Installation orientation: Vertical (±15° tolerance)
Combination unit integrating precision air filtration and pressure stabilization, featuring dual-chamber design with automatic condensate separation. The aluminum housing provides enhanced heat dissipation, while the transparent polycarbonate bowl allows visual monitoring of contamination levels. Includes tamper-proof adjustment knob with locking ring for stable pressure settings.
- Pneumatic instrument air preparation systems
- Robotic arm end-effector control circuits
- Laser cutting machine air knife assemblies
- Pharmaceutical blister packaging equipment
- Semiconductor wafer handling robotics
Maintenance protocol:
Drain condensate daily using manual drain button. Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05 MPa. Use only AirTAC PFR-5 replacement cartridges.
| Property | Property Value |
|---|---|
| sku | GPFR20006SJND |
| Port Size | PT1/8 |
