Airtac GPFR Pressure Regulating Precision Filter GPFR20006SM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006SM Precision Regulating Filter Specifications
- Model: GPFR20006SM
- Type: Pressure-regulated filter with 5μm filtration
- Port size: PT1/4 (G1/4 optional)
- Maximum flow rate: 2000 L/min (ANR)
- Operating pressure range: 0.05–1.0 MPa
- Pressure gauge range: 0–1.6 MPa (rotatable dial)
- Filter element: Sintered stainless steel (replaceable)
- Water bowl material: Polycarbonate (PC) with anti-static coating
- Drain type: Manual or semi-automatic (optional)
- Temperature range: -10℃ to 60℃ (non-freezing)
- Weight: 680g ±5% (dry)
- Dimensions: 150mm(H) × 100mm(W) × 85mm(D)
- Thread torque limit: 12–15 N·m
- Pressure adjustment knob: 360° rotatable with lock ring
High-efficiency coalescing filter with integrated pressure regulation, featuring dual-stage filtration (40μm pre-filter + 5μm final filter). The transparent bowl allows visual debris monitoring, while the ergonomic knob enables precise pressure control (±0.02 MPa stability). Includes built-in silencer for exhaust air.
- CNC machine pneumatic tool stations
- Pharmaceutical packaging air preparation
- Laser cutting machine air curtain systems
- Semiconductor cleanroom pneumatic controls
- Automotive painting robots
Maintenance protocol:
Replace filter element every 8,000 operational hours or when pressure drop exceeds 0.1 MPa.
Always depressurize before bowl removal. For vertical installation only.
| Property | Property Value |
|---|---|
| sku | GPFR20006SM |
| Port Size | PT1/8 |
