Airtac GPR Precision Pressure Regulator GPR20006HJN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR20006HJN Precision Pressure Regulator Specifications
- Model: GPR20006HJN
- Type: Precision pressure-reducing valve with pressure gauge port
- Port size: PT1/4 (G1/4 optional)
- Pressure range: 0.05–0.85 MPa
- Max flow capacity: 1,200 L/min (ANR)
- Pressure regulation accuracy: ±0.008 MPa
- Operating temperature: -5℃ to 60℃ (no freeze)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (hydrogenated nitrile)
- Weight: 410g ±5% (without gauge)
- Dimensions: 72mm(W) × 58mm(H) × 45mm(D)
- Gauge thread: M6×1.0 (1/8 NPT optional)
- Pressure relief: Built-in overflow function
- Mounting orientation: Vertical ±15° recommended
- Protection rating: IP40 (dust resistant)
High-precision pressure regulator with integrated gauge port and tamper-proof adjustment knob. Features dual-chamber diaphragm design for stable output under fluctuating input pressures. The corrosion-resistant HNBR seals and aluminum body ensure durability in humid environments. Requires 5μm filtered air and periodic lubrication (ISO VG32 oil mist recommended).
- Precision pneumatic instrumentation calibration
- Automated assembly line pressure control
- Medical gas pressure regulation systems
- Semiconductor manufacturing equipment
- Packaging machinery pressure stabilization
Installation note:
Install downstream of main filter regulator. For optimal performance, maintain 0.3-0.5 MPa higher input pressure than required output. Perform pressure adjustment clockwise while monitoring connected gauge. Drain condensate weekly via bottom vent.
| Property | Property Value |
|---|---|
| sku | GPR20006HJN |
| Port Size | PT1/8 |
