Airtac GPR Precision Pressure Regulator GPR40008HN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR40008HN Precision Pressure Regulator Specifications
- Model: GPR40008HN
- Type: Precision pressure regulator with gauge port
- Port size: PT1/4 (BSPP thread)
- Pressure range: 0.05–0.85 MPa (7–123 PSI)
- Flow capacity: 3,500 Nl/min (ANR)
- Operating temperature: -5℃ to 60℃ (no freezing)
- Accuracy: ±0.008 MPa within 20-80% of set pressure
- Body material: Aluminum alloy (anodized finish)
- Diaphragm: NBR rubber reinforced with polyester
- Weight: 420g ±5% (including gauge)
- Dimensions: 105mm(H) × 50mm(W) × 50mm(D)
- Gauge type: 40mm dial, 0-1.0 MPa scale
- Relief function: Built-in safety exhaust
- Mounting: Direct pipeline installation (horizontal/vertical)
High-sensitivity pressure regulator featuring dual-stage filtration (40μm + 5μm mesh) and anti-vibration gauge mounting. The balanced diaphragm design maintains stable output pressure under fluctuating flow conditions. Includes T-handle for tool-free adjustment and lockable pressure setting.
- Precision pneumatic instrument air supply
- Automated assembly line pressure control
- Medical gas pressure regulation systems
- Semiconductor manufacturing equipment
- Laser cutting machine air pressure stabilization
- Install downstream of main filter with vertical gauge orientation
- Lubricate quarterly with ISO VG32 turbine oil if used in dry air systems
- Replace diaphragm every 500,000 cycles or 2 years (whichever first)
- Use torque wrench for port connections (recommended 15-20 Nm)
Critical note:
Requires pre-filtering when used with unregulated air sources.
Avoid rapid pressure surges exceeding 1.2 MPa to prevent diaphragm rupture.
| Property | Property Value |
|---|---|
| sku | GPR40008HN |
| Port Size | PT1/4 |
