Airtac GTC Air Treatment Combination GTC20006LK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006LK Technical Specifications
- Model: GTC20006LK
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT3/8 (G1/2 optional)
- Operating pressure range: 0.05-1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration grade: 40μm (5μm optional element available)
- Adjustment accuracy: ±0.02 MPa
- Oil cup capacity: 150cc
- Air flow capacity: 3,500 Nl/min
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Weight: 1.2 kg (with full oil)
- Dimensions: 160mm(L) × 70mm(W) × 170mm(H)
- Body material: Die-cast aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Pressure gauge: 1/8" BSPT connection, 0-1.6 MPa range
Modular FRL unit combining 3-stage air preparation with enhanced water separation efficiency (85%+ at 0.7 MPa). Features twist-lock bowl design for tool-free maintenance and transparent polycarbonate reservoir with anti-static coating. The integrated bypass valve maintains airflow during filter replacement.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Automated packaging machinery
- Plastic injection molding machines
- Food processing pneumatic circuits (food-grade oil option)
Installation protocol:
Install vertically with arrow marking aligned to airflow direction.
Maintain 200mm clearance below for bowl removal. Drain condensate daily
in humid environments. Recommended oil viscosity: ISO VG32-68.
| Property | Property Value |
|---|---|
| sku | GTC20006LK |
| Port Size | PT1/8 |
