Airtac GTC Air Treatment Combination GTC20006LN
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triplex Unit GTC20006LN Technical Details
- Model: GTC20006LN
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT3/8 (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Filtration grade: 5μm (auto-drain version)
- Pressure regulation range: 0.05–0.85 MPa
- Lubricator capacity: 150cm³
- Max flow rate: 2000 NL/min
- Weight: 1.8kg (dry), 2.1kg (with oil)
- Dimensions: 150mm(L) × 80mm(W) × 185mm(H)
- Material: Die-cast aluminum body, PPS bowl
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" dial type (Glycerin-filled optional)
Modular FRL unit with integrated pressure adjustment lock mechanism and bowl guard. Features transparent bowl with metal protector, dual-scale pressure gauge (MPa/psi), and drip-feed lubricator with adjustable oil output (0-60 drops/min). Designed for centralized pneumatic preparation in medium-duty systems.
- CNC machine tool pneumatic circuits
- Automated assembly line air preparation
- Plastic injection molding machines
- Packaging machinery air line conditioning
- Robotic actuator systems
Installation guidelines:
Mount horizontally with arrow marking aligned to airflow direction.
Maintain 300mm clearance below lubricator for oil cup maintenance.
Replace filter element every 4,000 operational hours in normal conditions.
| Property | Property Value |
|---|---|
| sku | GTC20006LN |
| Port Size | PT1/8 |
