Airtac GTC Air Treatment Combination GTC20006LNK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006LNK Technical Specifications
- Model: GTC20006LNK (Filter-Regulator-Lubricator Unit)
- Port size: PT1/2 (Rc1/2 equivalent)
- Max operating pressure: 1.0 MPa
- Filtration rating: 5 μm (with auto-drain)
- Pressure regulation range: 0.05-0.85 MPa
- Lubricator capacity: 180 cm³
- Flow capacity: 2000 NL/min
- Temperature range: -5℃ to 60℃ (non-freezing)
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR + Fluororubber hybrid
- Weight: 1.25 kg (with bracket)
- Dimensions: 198mm(L) × 102mm(W) × 152mm(H)
- Mounting: Panel or rail (G3/8 adapter optional)
- Pressure gauge: M6 threaded, 1/8 BSP dial
Industrial-grade FRL unit combining particulate filtration (40μm stainless mesh), precision pressure regulation (±0.02MPa stability), and adjustable oil mist lubrication (2-3 drops/min). Features twist-lock bowl design for tool-free maintenance and impact-resistant polycarbonate bowl with safety shield. Includes bypass lever for emergency operation.
- Pneumatic tool supply systems in automotive assembly
- CNC machine air preparation stations
- Packaging line actuator control systems
- Plastic injection molding machine air circuits
- Foundry equipment compressed air conditioning
Installation protocol:
Install vertically in sequence (filter→regulator→lubricator) downstream of receiver tank.
Maintain 30cm upstream straight piping. Drain bowl weekly - lubricant level should not
exceed 80% capacity. Use ISO VG32-68 turbine oil only.
| Property | Property Value |
|---|---|
| sku | GTC20006LNK |
| Port Size | PT1/8 |
