Airtac GTC Air Treatment Combination GTC20006LNW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006LNW Technical Specifications
- Model: GTC20006LNW (FRL Combination Unit)
- Type: Filter-Regulator-Lubricator with bracket assembly
- Port size: 1/4" BSPP (G1/4)
- Operating pressure range: 0.15–1.0 MPa
- Filtration grade: 5 μm (auto-drain version)
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Adjustment range: 0.05–0.85 MPa
- Oil cup capacity: 130 cm³ (transparent polycarbonate)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Body material: Aluminum alloy (filter bowl: PC + protection cover)
- Weight: 1.2 kg (with bracket)
- Dimensions: 180mm(H) × 100mm(W) × 60mm(D) (mounting pitch)
- Flow capacity: 2000 L/min (ANR)
- Drain type: Manual/Auto drain optional (specify when ordering)
- Viscosity range: ISO VG32-68 turbine oil (recommended)
Integrated FRL unit combining 40μm particulate filtration, precision pressure regulation, and adjustable lubrication. Features a safety relief valve, impact-resistant PC bowl with metal guard, and tool-free bowl removal. The regulator includes a lockable knob with ±0.2% hysteresis accuracy. Optional auto-drain version prevents accumulated moisture in continuous operation.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated assembly line tooling stations
- Packaging machinery air supply conditioning
- Industrial robot end-effector support systems
Installation guidelines:
Mount vertically with arrow marking aligned to airflow direction (filter→regulator→lubricator sequence).
Maintain 50mm clearance below drain port. Lubricator oil level should be kept between 1/3-2/3 capacity.
Replace filter element every 6 months in normal operation.
| Property | Property Value |
|---|---|
| sku | GTC20006LNW |
| Port Size | PT1/8 |
