Airtac GTC Air Treatment Combination GTC20006SK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triplex Unit GTC20006SK Technical Details
- Model: GTC20006SK (Filter-Regulator-Lubricator Combination)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Maximum pressure: 1.0 MPa
- Filter micron rating: 5μm (40μm first stage)
- Pressure gauge range: 0–1.0 MPa
- Adjustable pressure: 0.05–0.85 MPa
- Flow capacity: 2000 L/min (ANR)
- Oil cup capacity: 100ml (polycarbonate)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 70℃
- Weight: 850g ±3% (with oil)
- Dimensions: 200mm(H) × 80mm(W) × 80mm(D)
- Protection rating: IP42 (standard configuration)
- Drain type: Manual drain (semi-automatic option available)
Integrated FRL unit combining precision filtration (dual-stage with bowl guard), pressure regulation with lockable knob, and adjustable lubrication. Features transparent oil bowl with anti-burst design and pressure gauge with dual-scale (MPa/psi). The modular structure allows individual component replacement. Requires 7-10 bar compressed air input.
- Pneumatic production line air preparation systems
- CNC machine tool pneumatic circuits
- Automated assembly equipment maintenance units
- Packaging machinery air supply conditioning
- Industrial robot end-effector support systems
Installation protocol:
Mount vertically with filter unit upstream. Maintain minimum 300mm clearance below drain port.
Lubricator should operate at 1/3 bowl capacity. Replace filter element after 5,000 hours or when
pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTC20006SK |
| Port Size | PT1/8 |
