Airtac GTC Air Treatment Combination GTC20006SNW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC20006SNW Modular FRL Unit (Filter-Regulator-Lubricator) Specifications
- Model: GTC20006SNW
- Type: 3-in-1 Combination Unit (Compressed Air Treatment)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–0.8 MPa
- Filtration grade: 40μm (5μm optional with different filter element)
- Pressure regulation range: 0.05–0.85 MPa
- Oil cup capacity: 150cm³
- Maximum flow rate: 2000 L/min (ANR)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (filter bowl: Polycarbonate)
- Weight: 0.65kg (dry)
- Dimensions: 105mm(W) × 100mm(D) × 120mm(H)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0MPa scale)
- Drain type: Manual drain button with splash guard
- Protection rating: IP42 (standard configuration)
Modular compressed air treatment unit combining precision filtration (with auto-drain function), pressure regulation with lockable knob, and adjustable lubrication. Features transparent polycarbonate bowl for visual monitoring and tool-free bowl removal. The corrosion-resistant design includes a drip-proof lubricator with flow control valve (0-8 drops/min adjustment).
- Pneumatic tool air preparation systems
- Packaging machinery main air line conditioning
- Automated assembly line pneumatic circuits
- CNC machine tool pneumatic component protection
- Food processing equipment (using food-grade lubricant)
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below drain port. Lubricator should be
positioned after equipment using oil-free air. Replace filter element
when pressure drop exceeds 0.1MPa.
- Daily: Manual drain activation (3-5 sec purge)
- Monthly: Bowl inspection for cracks/contamination
- 6 months: Filter element replacement
- Annual: Full disassembly cleaning
| Property | Property Value |
|---|---|
| sku | GTC20006SNW |
| Port Size | PT1/8 |
