Airtac GTC Air Treatment Combination GTC20008LW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008LW Technical Details
- Model: GTC20008LW
- Type: Compact FRL combination unit (Filter-Regulator-Lubricator)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 3,500 L/min (ANR)
- Filter rating: 40μm (5μm optional element available)
- Pressure gauge: Built-in 1/8" dial gauge 0-1.6MPa
- Adjustment knob: Lockable rotary type with ±2% regulation accuracy
- Drain type: Automatic float drainage
- Body material: Die-cast aluminum alloy (anodized finish)
- Seal material: HNBR rubber (-20℃ to 80℃)
- Weight: 1.45 kg ±5%
- Dimensions: 210mm(H) × 110mm(W) × 85mm(D)
- Mounting: ISO modular bracket system
- Air viscosity range: 10–300 cSt (ISO VG32 recommended)
Modular compressed air treatment unit combining particulate filtration, precision pressure regulation, and adjustable lubrication functions. Features a transparent polycarbonate bowl with anti-blowout safety structure and auto-drain mechanism. The LW suffix indicates a left-side water bowl configuration with wall-mount optimized profile.
- Pneumatic production line main air supply conditioning
- CNC machine tool pneumatic systems
- Packaging machinery air preparation
- Automated assembly line junction units
- Food processing equipment (FDA-compliant lubricant option)
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below drain port. Lubricator function should be
positioned after filter-regulator section. Replace filter element every
5,000 operating hours or when pressure drop exceeds 0.1MPa.
| Property | Property Value |
|---|---|
| sku | GTC20008LW |
| Port Size | PT1/4 |
