Airtac GTC Air Treatment Combination GTC20008SN
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triplex Unit GTC20008SN Technical Specifications
- Model: GTC20008SN
- Type: Filter-Regulator-Lubricator (F.R.L) combination unit
- Port size: PT 1/2 (G1/2 equivalent)
- Maximum flow: 3,500 L/min (ANR)
- Operating pressure range: 0.05–1.0 MPa
- Filtering precision: 5 μm (40μm optional)
- Regulator adjustment range: 0.05–0.85 MPa
- Lubricator oil capacity: 180 cm³
- Oil droplet adjustment: 1-5 drops/min
- Temperature range: -5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (filter bowl: PC)
- Weight: 1.2 kg (dry), 1.4 kg (with oil)
- Dimensions: 200mm(L) × 100mm(W) × 150mm(H)
- Pressure gauge: 1/8" BSPT, 0-1.6 MPa range
- Drain type: Manual float-type (auto-drain optional)
Industrial-grade F.R.L unit combining 3-stage air preparation: 5μm particulate filtration with automatic condensate drainage, precision pressure regulation with lockable knob, and adjustable micro-lubrication. Features anti-corrosion coating and impact-resistant polycarbonate bowl with metal guard. Designed for heavy-duty pneumatic systems requiring stable air quality.
- CNC machine pneumatic control systems
- Automated assembly line actuators
- Packaging machinery air preparation
- Plastic injection molding equipment
- Food processing pneumatic tools (oil-free option available)
Installation guidelines:
Install vertically with flow arrow alignment. Maintain 50cm downstream piping before equipment.
Replace filter element every 2,000 hours in normal conditions. Lubricator requires ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | GTC20008SN |
| Port Size | PT1/4 |
