Airtac GTC Air Treatment Combination GTC20008SNW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triplex Unit GTC20008SNW Technical Specifications
- Model: GTC20008SNW
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/2 (BSP 1/2")
- Operating pressure: 0.1-1.0 MPa
- Filtration grade: 5 μm (with auto-drain)
- Adjustable pressure range: 0.05-0.85 MPa
- Max flow rate: 2000 L/min (ANR)
- Lubricator oil capacity: 180 cm³
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (nitrile rubber)
- Weight: 2.5 kg (dry)
- Dimensions: 200mm(H) × 150mm(W) × 100mm(D)
- Mounting: Bracket or panel mount (M5 screw holes)
- Pressure gauge: 63mm dial (MPa scale)
Industrial-grade triplex unit combining precision filtration (5μm particulate removal), pressure regulation with lockable knob, and adjustable lubrication. Features a transparent polycarbonate bowl with metal guard, corrosion-resistant construction, and dual-scale pressure gauge (MPa/psi). Designed for continuous operation with 0.5% maximum pressure deviation.
- Pneumatic production lines in automotive manufacturing
- CNC machine tool air preparation systems
- Packaging machinery compressed air treatment
- Industrial robot end-effector control systems
- Plastic injection molding air circuits
Installation guidelines:
Install vertically with filter unit at bottom. Maintain minimum 300mm clearance below bowl for maintenance.
Lubricator should be positioned last in sequence. Use thread sealant on male ports only. Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GTC20008SNW |
| Port Size | PT1/4 |
