Airtac GTF Filter GTF20008
2. Both water and oil bowls utilize space-efficient short-type PC construction, enabling compact installations in space-restricted applications;
3. Equipped with differential pressure manual drainage mechanism for optimized fluid management.
Category: Filters | Brand: AirTAC | Series: GTF
AirTAC GTF Series Filter GTF20008 Technical Specifications
- Model: GTF20008
- Type: Auto-drain compressed air filter with pressure gauge
- Filtration grade: 5 μm (ISO 8573-1 Class 5)
- Maximum flow rate: 3,200 L/min (ANR)
- Operating pressure range: 0.15-1.0 MPa
- Port size: PT3/4 (BSPP thread)
- Filter element material: Sintered bronze with hydrophobic coating
- Drain type: Semi-automatic float drain
- Pressure gauge range: 0-1.6 MPa (standard dial size 40mm)
- Temperature range: -10℃ to 60℃ (non-freezing conditions)
- Weight: 1.85 kg (dry, without gauge)
- Dimensions: 180mm(H) × 125mm(W) × 125mm(D)
- Bowl capacity: 280 mL
- Material: Aluminum alloy body, polycarbonate bowl
- Thread sealant: Pre-applied PTFE tape
High-efficiency coalescing filter designed for industrial air preparation systems. Features a dual-stage filtration process with centrifugal separation for bulk water removal followed by precision coalescing filtration. The metal-braced polycarbonate bowl withstands mechanical stress and chemical exposure. Integrated pressure gauge allows real-time system monitoring.
- Pneumatic tool air line conditioning
- CNC machine air supply purification
- Paint spray booth compressed air systems
- Food processing pneumatic controls (FDA-compliant versions available)
- Robotic actuator protection
Installation note:
Install vertically with arrow marking aligned to airflow direction.
For optimal performance, maintain ambient temperature above dew point by 5℃.
Replace filter element every 4,000 operating hours or when pressure drop exceeds 0.07 MPa.
| Property | Property Value |
|---|---|
| sku | GTF20008 |
| Port Size | PT1/4 |
