Airtac GTFC Air Filter Regulator Combination GTFC20006LK
2. Equipped with compact short-type PC bowls for both water and oil reservoirs, delivering minimized installation footprint ideal for space-constrained applications;
3. Integrated differential pressure manual drainage mechanism for filter bowl water discharge.
Category: Air Treatment Combination Units | Brand: AIRTAC | Series: GTFC
AirTAC GTFC Series Twin Unit GTFC20006LK Technical Details
- Model: GTFC20006LK
- Type: Filter-Regulator Combination Unit (F.R.L. Twin)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 3,500 Nl/min
- Filtration grade: 40μm (5μm optional with different element)
- Adjustment knob rotation: 270° with lockable dial
- Pressure gauge: 1.5" dial, glycerin-filled (0-1.6 MPa scale)
- Weight: 1.8 kg (dry, without accessories)
- Dimensions: 180mm(H) × 150mm(W) × 105mm(D)
- Body material: Die-cast aluminum (anodized surface)
- Seal material: NBR & polyurethane hybrid
- Temperature range: -10℃ to 60℃ (non-freezing)
- Drain type: Manual lever with semi-auto discharge
- Mounting: Bracket slot compatible with 35mm DIN rail
Industrial-grade air preparation unit combining 40μm particulate filtration and precision pressure regulation. Features anti-vibration gauge, corrosion-resistant bowl, and ergonomic pressure adjustment with ±2% regulation accuracy. The integrated bypass design maintains airflow during filter element replacement.
- Pneumatic actuator control in assembly lines
- CNC machine tool air supply conditioning
- Packaging machinery pressure stabilization
- Robotic arm pneumatic systems
- Plastic injection molding air circuits
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Replace filter element when pressure drop exceeds 0.07MPa.
Daily condensate discharge recommended in humid environments.
| Property | Property Value |
|---|---|
| sku | GTFC20006LK |
| Port Size | PT1/8 |
